Thread Stem Swivel Caster

Thread Stem Swivel Caster
Product Introduction
WT2525
Product Name : Thread Stem Swivel Caster
Product No : WT2525
  • Load Capacity: 100-132LBS(45.4-60.1Kgs)Each caster.
  • Application: Excellent for Institution Equipment and Furniture and Hospital environment and Food Service Equipment and Tool Boxes.
  • Finish: Corrosion Resistant Zinc.
  • Option: Side Locking Brake( SB ).
Inquiry
TREAD WIDTH
INCH
( m/m )		 WHEEL TYPE BEARING AXIE SIZE
INCH
( m/m )		 CASTER
 NUMBER
1
( 25 )		 Soft Rubber (SR) Plain 5/16
( 7.9 )		 WT2525SR
Hard Rubber (HR) Plain WT2525HR
Polyurethane (U) Plain WT2525U
Thermoplastic (TPR) Plain WT2525TPR
Polypropylene (P) Plain WT2525P
Nylon (N) Plain WT2525N
LOAD
CAPACITY
  LBS ( Kgs )		 SWIVEL RADIUS
INCH
( m/m )		 OVERAL HEIGHT
INCH
( m/m )		 CASTER
 NUMBER
100 ( 45.4 ) 23/8
( 60 )		 33/8
( 86 )		 WT2525SR
100 ( 45.4 ) WT2525HR
120 ( 54.5 ) WT2525U
120 ( 54.5 ) WT2525TPR
120 ( 54.5 ) WT2525P
120 ( 54.5 ) WT2525N
THREAD STEM SIZE
INCH		 STEM
  NUMBER
1/2 - 13 x 1 D21
1/2 - 13 x 11/2
 D22
M12xP1.75-11/2
 D23
